Description

The BASIC pallet truck with weighing scale with 5 kg display increments is an ideal tool for straightforward weight measurement. With its capacity of 2000 kg, robust construction and user-friendly scales, it is the perfect aid for incoming goods inspection.
5 kg display increments up to 500 kg, 20 kg display increments over 500 kgMeasuring tolerance 500 kg ± 15 kg, 500 – 1000 kg ± 20 kg, 1000 – 1500 kg ± 30 kg, 1500 – 2000 kg ± 40 kgTare function and manual zero correctionElectronics and display protected against dust and moisture (IP 65 protection)2 x 1.5 V AA batteries
The BASIC weighing scale pallet truck is a robust entry-level model for simple controlled weighing

This hand pallet truck with scales is ideal for applications where the weight measurement is required but does not have to have optimal accuracy. The pallet truck with weighing scale is ideal for incoming goods control, determining shipping weights and avoiding truck overloads.

The result is displayed in 5 kg increments up to 500 kg, while 20 kg steps are used for weights in excess of 500 kg. Measuring tolerances: 50 – 500 kg ± 15 kg, 500 – 1000 kg ± 20 kg, 1000 – 1500 kg ± 30 kg, 1500 – 2000 kg ± 40 kg. Operation of the scales could not be simpler. As soon as you have inserted the batteries (2 x 1.5 V / AA), the scales are ready to perform approx. 3000 weighing operations. To minimise energy consumption, the scales switch off automatically when not used for approx. 2 minutes. The glare-free LCD display for the scales, which features a digit height of 18 mm, is located on the front of the pallet truck and can be easily read from all sides. The display and electronics of the scales are protected against dust and moisture (IP 65 protection).

The welded, sectional steel frame is torsion-free and very hard-wearing. As a result, the pallet truck retains its shape even under heavy loads of 2000 kg. Entry rollers ensure easy pallet insertion. The steering castors are solid rubber, while the fork rollers are made from polyurethane – an effective combination that delivers excellent grip with minimal noise. You can choose between single or tandem fork rollers. Tandem rollers offer smoother running and are better at handling uneven floors.

The robust BASIC weighing scale pallet truck with a capacity of 2000 kg is a versatile, cost-effective entry level model for straightforward weight measurement. Order this hand pallet truck with its user-friendly scales from our shop.
Drive
manual
Aisle width
1792 mm
Tiller height
1230 mm
Fork width
160mm
Fork roller diameter
74 mm
Fork height
48 mm
Overall width
540 mm
Overall length
1545 mm
Handle fittings
Steel
Pallet truck material
Steel
Face of forks length
390 mm
Steering wheel diameter
180 mm
Fork roller width
93 mm
Lift height per pump stroke
7,5 mm
Lift range
75 - 190 mm
Colour chassis
RAL 2002 blood orange
Battery capacity
1.2 Ah/per unit
Grease nipple
Yes
Power Supply Scale
Battery
IP protection type measuring cells
IP 65
Zero adjustment via keyboard
Yes
No. of batteries
2
  • local_shipping Free Delivery
  • Availability: 100

    Basic Hand Pallet Truck with weighing scales

    For simple, controlled, weighing

    • 2000kg capacity
    • Weighing scales
    • 1150mm fork length
    • Rubber wheels

    €559.00
    Tax excluded
    171132
    Status: In stock

    Delivery: 2-3 Week Delivery
