Jungheinrich AMX 10 Scissor Lift Hand Pallet Truck
Jungheinrich AMX 10 Scissor Lift Hand Pallet Truck

Description

The AMX 10 scissor lift pallet truck delivers premium Jungheinrich quality in a highly versatile package. You can use it as a hand pallet truck, lift table, provisioning table or workbench. With just a few pumps of the tiller, you can raise loads weighing up to 1000 kg to a comfortable, fatigue-free working height. As of a lift height of 400 mm, support feet provide additional stability and security for the scissor lift pallet truck.
Flexible application, can also be used as a lift table or workbenchAutomatic quick lift up to 120 kg800 mm lift height for ergonomic workingErgonomic tiller handle that can be operated with either handAvailable with optional lateral support rollersAlso available with electric lift
Just a few tiller strokes raise the load to a comfortable, ergonomic height.

The AMX 10 scissor lift pallet truck is a premium Jungheinrich product offering durable and reliable quality. As a combination between a pallet truck and lift table, the scissor lift pallet truck is extremely flexible and versatile.

Activities involving frequent bending and heavy lifting can quickly have an effect on employee health. Supported by the automatic quick lift up to 120 kg, loads weighing up to 1000 kg can be raised to an optimum ergonomic height with just a few pumps of the tiller. The truck thus serves as an invaluable aid when working with pallets or pallet cages. It goes without saying that you can also use the AMX 10 as a hand pallet truck to transport your goods.

The lift/travel/lower functions are controlled via the ergonomic tiller handle, which can be easily operated with either hand. Thanks to the special lowering valve, loads can be set down with utmost control and precision. You can adjust the working height of the AMX 10 up to a height of 800 mm. As of a lift height of around 400 mm, side-mounted support feet provide additional stability. They secure the pallet truck, which can then no longer move and thus serves as a useful work table. You also have the option of equipping the scissor lift pallet truck with lateral support rollers so that you can also move it when raised.

The fork arms with their closed fork tips and welded construction are torsion-free and highly durable. As a result, the scissor lift pallet truck retains its shape even under the heaviest loads. The single-stage lift cylinder makes the AMX 10 particularly resilient and minimises the risk of leaks. The overload valve protects against excess loads.

Depending on the ground conditions and specific application, you can choose between a range of wheel and roller materials. Order the versatile Jungheinrich scissor lift pallet truck from our shop in your chosen configuration.
Aisle width
2005 mm
Ground clearance
30 mm
Chassis surface
powder-coated
Fork length
1150 mm
Fork roller diameter
82 mm
Overall width
560 mm
Overall length
1650 mm
Load centre
600 mm
Steering wheel diameter
170 mm
Steering wheel material
Nylon (black)
Pump strokes to lift pallet
2
Capacity
1000 kg
Fork roller width
62 mm
Lift height per pump stroke
25/12 mm
Lift range
86 - 800 mm
Fork support width
560 mm
Model
Jungheinrich AMX 10 Scissor Lift Pallet Truck
Pump strokes to max. lift height
28/56
Lift type
manual
  • local_shipping Free Delivery
  • Jungheinrich AMX 10 Scissor Lift Hand Pallet Truck

    Manually raises loads to an ergonomic working height

    • Premium quality
    • Capacity 1000kg
    • Forks 1150mm x 560mm
    • Lift height 714 mm

    €1,169.00
    Tax excluded
    50437748
    Status: In stock

    Delivery: 2-3 Week Delivery
