Complete Pallet Racking type MPB - 3000mm Height

Description

Complete pallet racking system consisting of type MPB racking. Offers bay load capacity up to 6000kg with adjustable levels and a nominal height of 3000mm.

Product Details

Nominal Height: 3000 mm
Nominal Width: 8100 mm
Nominal Depth: 1100 mm
Compartment load max.: 3000 kg
Bay load max.: 6000 kg
Access options: double sided
Assembly: Plug-in assembly
Stand surface: powder coated
Shelf type: Pallet Rack
External dimension width: 8440 mm
External dimension height: 3000 mm
External dimension depth: 1100 mm
Field Type: Complete Package
Bearing Type: Deep Storage
Approvals: building authority approval (DIBt)
Security Notice: Shelf loads apply when the load is evenly distributed. Additional requirements are possible if the maximum bay load is observed. For static reasons, the installation of at least 3 shelf bays is required. Alternatives on request.
Stand Type: B'12 (85 / 17.5)
Standard Shelf: DIN EN 15512
Traverse Rack Colour: RAL 1007 daffodil yellow
Stand Rack Colour: RAL 5010 gentian blue
Number of levels: 2
Pallet Spaces: 27
Load capacity per pallet max.: 1000 kg
Line Type: Single Line
External dimensions of the cultivation area: Nominal width + 85 mm / nominal depth + 0 mm
External dimensions of the basic field: Nominal width + 170 mm / nominal depth + 0 mm
