Ameise® PTE 1.3 electric pallet truck - Lithium Ion, 800mm forks
- Capacity 1300kg
- Forks 800mm
- Lithium-ion battery
- PU Wheels
- Suitable for light use (up to 3hrs per day)
- local_shipping Free Delivery
Description
The Ameise® SPM 113 electric pallet truck combines a traditional hand pallet truck with the benefits of an electric low lift truck. Thanks to its electric drive system, it represents an invaluable aid for handling pallets weighing up to 1300 kg. The unique, semi-electric hand pallet truck for in-house goods transport is exclusive to our shop.
Drive system with two-stage travel speedHigh-quality Ameise® hydraulic pump technologyMaintenance-free lead-gel batteryOn-board charger for 230 V socketsAutomatic stand-by mode when not in use
Our Ameise® pallet truck with electric drive system – for manual lifting and electric travel
The SPM 113 pallet truck is designed for light-duty use as part of your in-house goods transport. The electric drive system features a 2-stage travel speed and assists you in handling loads weighing up to 1300 kg. Powerful, tried-and-tested Ameise® hydraulic pump technology assists you with the manual lifting of the palletised goods.
You operate and steer the semi-electric pallet truck via the ergonomic tiller handle. Forward and backward travel is controlled via the buttons at the top of the tiller head. By pressing the crawl speed button, you can reduce the travel speed to enable safe and convenient transport of even the most sensitive goods in narrow warehouse aisles. The compact dimensions and small turning circle ensure excellent manoeuvrability.
The drive system of the electric pallet truck is powered by a long-life 30 Ah lead-gel battery, which you can charge via any 230 V socket thanks to the on-board charger. The lead-gel battery is maintenance-free since it does not have to be topped up with water. The residual capacity of the battery is shown by the battery charge indicator on the tiller head. If the SPM 113 remains unused for 5 minutes, it automatically switches to stand-by mode. Thanks to this efficient energy consumption, the daily operating time and availability of the pallet truck is greatly increased.
The drive wheel and tandem fork rollers are made from durable polyurethane and offer high-quality, comfortable and quiet travel combined with maximum capacity and a long service life.
The Ameise® SPM 113 electric hand pallet truck with 1150 mm fork length serves as an invaluable aid when handling pallets weighing up to 1300 kg. Order the pallet truck with the outstanding price/performance ratio from our shop today.
The SPM 113 pallet truck is designed for light-duty use as part of your in-house goods transport. The electric drive system features a 2-stage travel speed and assists you in handling loads weighing up to 1300 kg. Powerful, tried-and-tested Ameise® hydraulic pump technology assists you with the manual lifting of the palletised goods.
You operate and steer the semi-electric pallet truck via the ergonomic tiller handle. Forward and backward travel is controlled via the buttons at the top of the tiller head. By pressing the crawl speed button, you can reduce the travel speed to enable safe and convenient transport of even the most sensitive goods in narrow warehouse aisles. The compact dimensions and small turning circle ensure excellent manoeuvrability.
The drive system of the electric pallet truck is powered by a long-life 30 Ah lead-gel battery, which you can charge via any 230 V socket thanks to the on-board charger. The lead-gel battery is maintenance-free since it does not have to be topped up with water. The residual capacity of the battery is shown by the battery charge indicator on the tiller head. If the SPM 113 remains unused for 5 minutes, it automatically switches to stand-by mode. Thanks to this efficient energy consumption, the daily operating time and availability of the pallet truck is greatly increased.
The drive wheel and tandem fork rollers are made from durable polyurethane and offer high-quality, comfortable and quiet travel combined with maximum capacity and a long service life.
The Ameise® SPM 113 electric hand pallet truck with 1150 mm fork length serves as an invaluable aid when handling pallets weighing up to 1300 kg. Order the pallet truck with the outstanding price/performance ratio from our shop today.
Product Details
- Drive
- electric
- Aisle width
- 1869 mm
- Control panel
- two-handed
- Operator type
- Pedestrian
- Ground clearance
- 35 mm
- Chassis surface
- Painted
- Tiller surface
- Painted
- Route
- Short distance
- Tiller RAL colour
- RAL 7046 telegrey 2
- Fork width
- 150 mm
- Fork length
- 1150 mm
- Fork roller diameter
- 80 mm
- Fork roller material
- Polyurethane (PU)
- Fork roller equipment
- Tandem
- Fork height
- 50 mm
- Overall width
- 560 mm
- Overall length
- 1588 mm
- Handle fittings
- Rubber sheath
- Pallet truck material
- Steel
- Face of forks length
- 438 mm
- Load centre
- 600 mm
- Steering wheel diameter
- 210 mm
- Steering wheel material
- Polyurethane (PU)
- Turning radius
- 1415 mm
- Capacity
- 1300 kg
- Steering wheel width
- 70 mm
- Fork roller width
- 60 mm
- Lift range
- 85 - 200 mm
- Fork support width
- 560 mm
- Travel speed, laden/unladen
- 3,4 / 4,0 km/h
- Battery type
- Lead gel battery
- Battery voltage
- 24 V/per unit
- Battery capacity
- 30 Ah/per unit
- Net weight incl. battery
- 145 kg
- Noise level as per EN 12053 (operator's ear)
- 74 dB (A)
- Lift type
- manual
- Gradeability
- 6%
- Charger
- integrated
- Max. gradeability laden/unladen
- 2 / 6%
- Battery weight
- 19 kg
- Brake
- electromagnetic
- Drive motor power
- 0.65 kW
- Chassis RAL Color
- RAL 5018 turquoise blue
- Display
- Discharge monitor
Availability: 100
Ameise® SPM 113 Electric Hand Pallet Truck, 1150 forks
For electric transport and manual lifting
- Capacity 1300 kg
- Forks 1150 mm
- Fork width 560 mm
- PU Wheels
- Suitable for light use (up to 3hrs per day)
